homogenizing chamber and a pressurization mechanism.Under the action of the pressurization mechanism,the high-pressure solution rapidly passes through the homogenizing chamber with a specially designed geometric shape.The material simultaneously undergoes mechanical forces such as high-speed s hearing, high-frequency oscillation,cavitation phenomenon,and convective impact,as well as corresponding thermal effects,thereby causing changes in the physical,chemical, and structural properties of the material,ultimately achieving the homogenization effect.
|
Model
|
BXT-HP10
|
BXT-HP20
|
BXT-HP50
|
|
Maximum flow
|
10-15L/H
|
20-23L/H
|
10-40L/H
|
|
Output
|
15ML-10L/H
|
18ML-23L/H
|
50ML-40L/H
|
|
Minimum processing capacity
|
15ML
|
20ML
|
50ML
|
|
Design uniform pressure
|
Maximum 2000 bar
|
Maximum 1650bar
|
|
Maximum working pressure
|
1650bar
|
1500bar
|
15000bar
|
|
Main motor
|
1.5KW,Level 8
|
2.2KW,Level 8
|
5.5KW,Level 6
|
|
Voltage/Frequency
|
220V/50Hz/2-Phase
|
380V/50Hz/3-Phase
|
380V/50Hz/3-Phase
|
|
Process products
|
Nano emulsions, food emulsification, suspensions, liposomes, fat
emulsions, etc.
|
|
Product process viscosity
|
<2000cPs
|
|
Maximum feed particle size
|
<500μm
|
|
Homogenization stage number
|
First-level homogenization(homogenization, emulsification,
dispersion)
|
|
Pressure gauge
|
High-precision sanitary digital pressure sensor
|
|
Level / Plunger
|
Hygienic Grade / 1 Piece of Zirconia Ceramic
|
|
Internal cooling
|
Fan
|
|
Feed and discharge connection
|
Tri-Clamp Quick-Connect Chuck
|
|
Maximum cleaning temperature
|
<90°C
|
|
Maximum sterilization temperature
|
<145°C
|
|
Cleaning / Disinfection Time
|
30 minutes
|
|
Pressurization method
|
Manual pressurization
|
|
Split pump head
|
SAF2205
|
|
Guide plate
|
SUS316L
|
|
Homogenizing valve
|
Diamond
|
|
Overall dimensions
|
550x440x440mm
|
630x520x440mm
|
840x632x920mm
|
|
Net weight
|
150kg
|
150kg
|
240kg
|
1 .Pharmaceutical industry: It is a key equipment for preparing nano formulations,such as preparing fat emulsions,microemulsions,and liposomes (as targeted delivery carriers),precisely controlling particle size,and enhancing the bioavailability and stability of ;in vaccine preparation,it is used for antigen emulsification to ensure the immune effect.
2 .Biological Engineering:Primarily used for cell disruption and extraction of intracellular substances.It can efficiently disintegrate bacterial,yeast,fungal and other microbial cells,releasing intracellular enzymes,proteins,nucleic acids and other active substances,while avoiding the destruction of active components by high temperature (with a cooling system,the temperature can be controlled at ≤40℃).
3 .Food and Beverage Industry: In dairy products,such as milk and yogurt, homogenization breaks down fat globules to prevent stratification and improve the
texture;in juice and beverage production,fine grinding of fruit pulp enhances clarity and extends the shelf life;it can also be used to prepare nano-nutritional foods to increase the absorption rate of nutrients.
4 .Cosmetics and Fine Chemicals Industry:In the production of skin care products, the active ingredients are refined to the nanometer level to enhance skin permeability;in the field of pigments and coatings,the pigment particles (such as nano-titanium dioxide)are dispersed to improve color uniformity and coverage.
5 .Conductive Paste Preparation:For Conductive Pastes Used in Lithium -ion Batteries and Solar Cells (Such as Nanotube Slurries),to Improve Electrical Conductivity.
